MXHD88

8 X 8 4K @ 60 HDMI Matrix Presentation Switcher

This is a new fixed 4K60 HDMI matrix switcher with 8 HDMI2.0 inputs and 8 HDMI2.0 outputs, the resolution can up to 4K60Hz and all ports are HDCP2.2 compliant. With the friendly user control methods by IR remote control, 2-Press push buttons with background blue light, WEB GUI, APP and RS232/UDP commands, 8×8 4K60 HDMI matrix switcher can work with the Blu-Ray Players, Set-Top boxes, Home Theater, and game consoles etc HDMI input sources to route to the HDMI displays, it has been widely used in different audio visual. applications.

• 8 HDMI2.0 inputs with 3.5mm audio embedded for each input
• 8 HDMI2.0 outputs with 3.5mm audio de-embedded for each output
• Supports HDMI2.0, HDCP2.2• The resolution can up to 4K@60Hz
• Supports IR remote control(IR remote control codes are available)
• Supports LPCM 7.1CH, Dolby TrueHD, Dolby Digital and DTS-HD ,DTS:X,Atmos,Master Audio
• Supports IR remote control(IR remote control codes are available)
• Supports smart EDID management, including 8-output EDID, 15 internal EDISupports RS-232 and RJ45 TCP/IP Control(WEB GUI, APP and IR remote)
• Supports 2-press push buttons control with blue lights
• Supports to rename the inputs and outputs,scenes
