CS82
8’’ 2 WAY CEILING SPEAKERS
Introducing the LUCASACS CS82 flush-mount in-ceiling speakers tailored for those who truly care about performance. This set includes a total of two LUCASACS CS82 coaxial in-ceiling speakers, each boasting a robust 8″ woofer alongside a 1″ coaxial compression driver. Together, they deliver a powerful output of 80W RMS and 160W program power at 8Ω.
Designed with a built-in multi-tap transformer, these flush-mount in-ceiling speakers can support 70V/100V and 8Ω (low impedance) and can easily be adjusted using the baffle-mounted tap switch. This ensures a seamless integration with virtually any professional sound system. Flush-mount installation provides secure mounting to ceilings in both residential and commercial settings.
With its white-painted magnetic grill, the LUCASACS CS82 offers a sleek, elegant finish that matches many different types of environments and settings while the 120° conical sound coverage ensures immersive sound dispersion to your audience. This makes the LUCASACS CS82 flush-mount in-ceiling speakers an optimal choice for venues like restaurants, cafes, bars, lobbies, conference rooms, auditoriums, retail stores, casinos and much more!
- Technical Specifications
- Catalogue File
| Feature | Specification |
|---|---|
| Frequency Response | 65Hz – 20000Hz (± 3dB) / 60Hz – 20000Hz (-10dB) |
| Power Rating | 80/160 W @ 8 ohm – 3.75/7.5/15/30 W @ 70-100 V |
| Driver | LF 1×8‘’ + 1’’ Coaxial Compression Driver (In-Ceiling Speaker) |
| Maximum SPL | 114 dB SPL peak |
| Connection | Binding Post |
| Control | 70 V / 100 V / 8 ohm Tap Switch |
| Finish | White Painted |
| Dispersion Angle | 120° Conical |
| Dimensions | 290 x 113.4 H mm |
| Weight | 2.3 kg |
